Simpson Strong-Tie PSCA 1/2 Panel Sheathing Clip, 20 ga Thick Material, Steel, Zinc Galvanized
The PSCA is designed to brace unsupported sheathing edges when sheathing meets edge to edge without a rafter for support. This light sheathing clip provides a 1/8 in gap to address shrinkage and expansion of roof sheathing. Inserted over the edges of adjacent plywood panels, the PSCA reduces deflection and keeps panels even to maintain a level plane on the structure.
Product specification
Brand
Simpson Strong-Tie
UPC
707392469124
Model Number
PSCA 1/2
Feature
Quick-installation, no nails required
Feature
Provides a secure environment for sheathing
Feature
Support for shrinkage and expansion over time
Feature
Provides the 1/8 in space between plywood panels as recommended by the American Plywood Association
Feature
Use the same size sheathing clip as the panel thickness
Feature
For panel thickness of 1/2 in
Feature
Made from 20 ga steel
Feature
Galvanized (G90) for corrosion-resistance
Category
HARDWARE
Additional Category
FASTENERS
Additional Category
BUILDING MATERIALS
Additional Category
JOIST HANGERS & CONNECTORS
Additional Category
STRUCTURAL TIES & STRAPS
Additional Category
Plywood Clips
Length
4.38
Width
7.81
Height
10.31
Weight
2.5
